Product Overview
2 Air Pressure Gauges in 1
GlowShift’s 10 Color Digital Dual Air Pressure Gauge is electronically driven and reads 2 sections of your vehicle’s air ride suspension system independently from 0 to 200 PSI. Air pressure gauges are ideal for identifying and displaying if the air tank, air bags or air horn are supplying an adequate amount of pressure. This dual air pressure gauge features 2 customizable displays with bold, easy to read, quick glance digital readouts. Users have the ability to set each of the displays with any combination of the featured 10 colors to quickly identify which reading is which. Each dual air suspension gauge includes (2) 1/8-27 NPT electronic air pressure sensors, (2) 9’ sensor harnesses, (1) 2’ power harness, gauge visor and mounting hardware for a complete installation.
10 Color Digital Series Features
Each digital gauge features 10 different color options that include blue, green, red, yellow, white, teal, purple, pink, amber and orange by clicking the button on the gauge face. After the color orange, there are 2 additional modes that utilize each of the featured 10 colors: color cycle and color fade modes. This 10 Color Digital Gauge features a diameter of 2-1/16” (52mm) with a flat gauge face and ultra-thin design. The 2 digital displays measure at 0.66” x 0.36”. At startup, the gauge performs a self-calibration sequence to ensure it is functioning properly. For an easier viewing experience when driving at night, connect the orange wire from the power harness to the headlight switch source. This allows the gauge to dim 50% when the headlights are on for a more subtle glow.
GlowShift’s Guarantee
GlowShift stands behind each product by including installation instructions, free lifetime technical support and a one year limited warranty.
Note: This gauge includes a 1/8-27 NPT thread size on each pressure sensor, and your vehicle’s air system may not come equipped with the same thread size. Additional threading adapters may be required to install each sensor to its source. If you are unsure if your application will require additional threading adapters, please contact a GlowShift Technical Support Specialist.
- 2-1/16” (52mm) Black Face Gauge with a Low Profile Tinted Lens
- Dual Air Pressure Readings from 0 to 200 PSI
- 10 Color LED Options Include Blue, Green, Red, Yellow, White, Teal, Purple, Pink, Amber, & Orange
- 10 Color LED Cycle & Fade Mode
- (2) 1/8-27 NPT Electronic Air Pressure Sensors
- (2) 9’ Sensor Harnesses
- 2’ Power Harness
- Self-Calibration at Startup
- Dimmer Wire Allows the Gauge to Dim 50%
- Gauge Visor
- Mounting Hardware
- Installation Instructions
- Free Lifetime Technical Support
- One Year Limited Warranty
